Product name: Single-use 127mm Overburden Casing drilling ringbit

Product category: Overburden casing drilling system

Matched hammer: Hammer DHD340

Matched casing pipe OD: 127mm

Single-use Overburden Casing drilling ringbit description:

Original: Wuxue, Made in china

Delivery time: 20-30 days

Port of shipment: Wuxue, Shanghai, Yiwu, Shenzhen.

Color: Green, Blue, Red, Gold, Black, Custom Colors.

Price term: EXW, FOB, CFR, CIF, DDU

Overburden casing ring bit components:

Pilot bit + ring bit + casing shoe

Production details:

How to order:

Casing Tube OD & ID + Ring Bit Diameter + Hammer Shank + Maximal Normal Bit Diameter +

Casings and Casing Shoes Installation Method (if by threads, threads standard must be offered)

Products Advantage:

1. Enhance penetration and perpendicularity

2. Deal with straight, oblique hole and other angle holes

3. Material: TIMKIN Steel. Tungsten carbide: YK05, T6 from Element Six in Germany

4. Kingdrilling DTH tools are forged by advanced electron-hydraulic forging hammer, and harness process is managed by multipurpose furnace heat treatment.

5. Quality: More than 40 Years engineer to make sure the quality, 100% inspection

FAQ:

1. What is hole hammer?

Pneumatic down-the-hole (DTH) hammer is a pneumatic drilling tool using compressed air as a power source. It is suitable for drilling in pebble, gravel, and hard rock strata. It is often used in building pile foundation construction, bridge, mining, geological exploration, hydrological wells, and other fields.

2. What is overburden fill?

Overburden Soil is a general, unprocessed, fill material that can contain a variety of different materials, depending on where it is sourced. Overburden Soil can contain sand, rocks, clay and stones, and will typically lack the organic material and nutrients found in topsoil.

3. How far can you directional bore?

What are the minimum and maximum lengths of crossing? Maximum lengths and hole diameters are determined by project specific geotechnical conditions however effective outside range for heavy rig horizontal directional drilling is 3,000 m

Products Manufacturing:

Wuhan Kingdrilling Diamond CO., LTD, located in Wuhan East Lake High-tech Development Zone, is one of the most professional private enterprise specialized in researching and producing ODEX casing drilling system, symmetric casing drilling system, DTH hammer, DTH drill bits, Thread bits, Shank adapter, Drilling rods, Coal mining tools, Coupling sleeve, Anchoring and so on.

Relying on the university resources and talent advantages in Optical Valley region, combining with multiple laboratories in universities, we focused on developing the newest products system.

We produce DTH drilling tools with advanced technology from Britain, a completed manufacturing system has been formed in plant. The company is equipped with advanced production facilities including electron-hydraulic forging hammer, multipurpose furnace heat treatment production line, high performance CNC machines, all processes from raw materials prepared, forging, heat treatment, metal processing are completed in the factory. Strict quality control standards make sure stable quality.

Whatever in construction, engineering, piling, waterwell drilling, tunnelling, mining, quarrying or horizontal drilling industry. KINGDRILLING will always do the best to meet your demands. "Kingdrilling, Keep On Striving",  we’ll always be in this line to serve our customers the most reliable products and the best support.
