Product name: High Quality Carbide 11 Degree 34mm Tapered Cross Button Bits In
Marble Quarry
Product category: DTH taper drill bit
Matched connection: 11 degree taper
Diameter: 34mm
KINGDRILLING DTH taper drill bit description:
Tapered chisel drill bits have different tapers and are used for different rock
formations and rock drilling. Tapers of 11° and 12° are common on
modern drill rigs. The narrow taper of 7° is used for low impact
rock drills and softer rock formations.
Widely used for drilling large diameter holes in rocks for water
well drilling. Oil fields, coal mines, tunnels, mineral
exploration, geothermal drilling, subway engineering drilling.
Quarrying and construction projects such as roads and power
stations. Suitable for extremely hard, abrasive rock formations,
medium hard, homogeneous formations. Soft rock, fissure rock
formation, etc.
All tapered chisel drill bits are made of high-quality raw
materials and undergo special heat treatment. They have extremely
strong conveying capacity and can fully meet customers'
requirements for conveying design.
KINGDRILLING tapered drill bits parameters:
| Model | Bit Dia.(mm) | Tip size (mm) | Taper | Weight(kg) |
| MZ0732-7 | 32 | 5×7 2×7 | 7" | 0.3 |
| MZ0833-7 | 33 | 6×7 2×7 | 7" | 0.4 |
| MZ0735-7 | 35 | 5×8 2×7 | 7" | 0.4 |
| MZ0737-7 | 37 | 5×8 2×8 | 7" | 0.4 |
| MZ0438-7 | 38 | 3×9 1×9 | 7" | 0.3 |
| MZ0440-7 | 40 | 3×9 1×9 | 7" | 0.4 |
| MZ0741-7 | 41 | 5×9 2×7 | 7" | 0.5 |
| MZ0442-7 | 42 | 3×9 1×9 | 7" | 0.4 |
| MZ0543-7 | 43 | 3×9 2×9 | 7" | 0.4 |
| MZ0528-11 | 28 | 4×7 1×7 | 11" | 0.2 |
| MZ0530-11 | 30 | 4×7 1×7 | 11" | 0.2 |
| MZ0532-11 | 32 | 3×8 2×7 | 11" | 0.2 |
| MZ0632-11 | 32 | 4×7 2×7 | 11" | 0.2 |
| MZ0732-11 | 32 | 5×7 2×7 | 11" | 0.2 |
| MZ0734-11 | 34 | 5×8 2×7 | 11" | 0.3 |
| MZ0536-11 | 36 | 3×8 2×8 | 11" | 0.3 |
| MZ0636-11 | 36 | 4×8 2×8 | 11" | 0.3 |
| MZ0736-11 | 36 | 5×8 2×8 | 11" | 0.3 |
| MZ0738-11 | 38 | 5×8 2×8 | 11" | 0.4 |
| MZ0741-11 | 41 | 5×9 2×8 | 11" | 0.4 |
| MZ0732-12 | 32 | 5×7 2×7 | 12" | 0.3 |
| MZ0735-12 | 35 | 5×8 2×7 | 12" | 0.4 |
| MZ0737-12 | 37 | 5×8 2×8 | 12" | 0.4 |
| MZ0741-12 | 41 | 5×9 2×8 | 12" | 0.5 |
| MZ0743-12 | 43 | 5×9 2×8 | 12" | 0.5 |
| MZ0745-12 | 45 | 5×9 2×9 | 12" | 0.5 |
How to order
Tapered Drill Bits: Bit Diameter + Taper Degree + Socket Diameter.
Kingdrilling tapered drill button bits application:
1. Mineral
2. Tunneling & Underground Project
3. Construction Drill And Blast
4. Quarrying & Aggregate
5. Hydropower Project
Kingdrilling tapered chisel bits advantages:
1. High rock drilling efficiency and stable performance
2. Strong wear resistance, long service life, greatly saving costs.
3. Simple structure, easy to use and maintain
4. Durable. Bismuth tin, high density
5. Fast drilling speed, no grinding required
FAQ:
1.What is the general delivery time?
15 working days for DTH bits.
20-25 working days for DTH hammer
3-5 working days for ex stock items.
2. Competitive pricing:
A: Since KINGDRILLING factory sells directly to consumers without
the need of a distributor, it can provide you the best price.
3. How do I select the DTH drill bit's appropriate head face?
Concave: Excellent for perpendicularity of the hole and appropriate
for drilling deep wells in a variety of formations.
Convex: Good drilling efficiency, moderate borehole
perpendicularity, and appropriate for the development of strata
with a moderate degree of hardness.
Flat: This type of drilling is well suited for tough strata,
particularly those with fractures, adequate fracture spacing, and a
well-perpendicular borehole.
4. A feature of the product
Innovative electron-hydraulic forging hammers are used to forge
kingdrilling DTH tools, and multipurpose furnace heat treatment
controls the harness process.
